Lithium polymer Battery is a combination of a cylindrical and a rectangular shaped structure. The internal structure is bounded spirally that helps in creating a partition between the anode and the cathode portions of the battery by putting a concise and highly porous polyethylene layer between the two.
Also, as explained earlier, Lithium polymer batteries work on the principle of using liquid electrolyte solution, so a portion of the battery is filled with organic liquid electrolyte solution. Also, to protect the lithium polymer battery from unprecedented incidents such as short circuit or explosions, safety valves, and PTC components are installed.
Followed by these, lithium polymer battery cells are installed either in a series or parallel to one another. The number of lithium polymer battery cells varies depending on the total voltage requirement of the battery. The voltage of one cell is 3.6V and the total voltage of the battery is the sum of the voltage of the cells installed.
A lithium polymer battery, or more correctly lithium-ion polymer battery (abbreviated as LiPo, LIP, Li-poly, lithium-poly and others), is a rechargeable battery of lithium-ion technology using a polymer electrolyte instead of a liquid electrolyte. High conductivity semisolid (gel) polymers form this electrolyte. Lithium polymer battery provide higher specific energy than other lithium battery types and are used in applications where weight is a critical feature, such as mobile devices, radio-controlled aircraft and some electric vehicles.Lithium polymer are pacifically used on products and appliances where weight is a crucial feature,as in,where already wight is a special consideration.
VTC Power provides customized size of Lithium polymer battery,thousands of lithium polymer battery tools available now.All the lithium polymer battery passed the strict safety and reliablility test and certificated.VTC Power Lithium polymer battery is widely used in POS terminal,IOT device,light,portable electronics,smart watch,GPS etc.
Lithium polymer battery Features:
1. High operating voltage (3.7V average, 4.2 volts peak)
2. Energy density is high, volumetric energy density of 350Wh/L and gravimetric energy
density of 135Wh/kg.
3. No memory effect
4. Self-discharge is less than 2% per month
5. Charge/discharge cycle characteristics are excellent
6. Safety characteristics are excellent
7. The battery has a wide discharging temperature range of -20 °C to +60 °C
8.VTC Power also specially designed low temp and high temp Lithium polymer battery.
