Model: VTC-16LF100
Nominalvoltage: 48V
Nominal capacity: 100Ah
Internal Resistance: ≤80mΩ
Life Cycles: ≥2000
Maximum Charge Voltage:58.4V
Cut-off Discharge Voltage: 36.9V
Continuous Discharge Current:100A
Battery Weight: 64Kg
Measurement: 177*410*452mm
Model: VTC-L18650
Nominalvoltage: 74V
Internal Impedance：≤40 MΩ
Nominal capacity: 13Ah
Life Cycles: ≥2000
Continuous Discharge Current:100A
Battery Weight: 6Kg
Model: VTC-16LF100
Nominalvoltage: 48V
Nominal capacity: 100Ah
Internal Resistance: ≤80mΩ
Life Cycles: ≥2000
Maximum Charge Voltage:58.4V
Cut-off Discharge Voltage: 36.9V
Continuous Discharge Current:100A
Battery Weight: 60Kg
Measurement: 450*550*210mm
Model: VTC-LF280
Nominalvoltage: 3.2V
Nominal capacity: 280Ah
Internal Resistance: ≤0.25mΩ
Life Cycles: ≥2000
Maximum Charge Voltage:3.65V
Cut-off Discharge Voltage: 2.3V
Continuous Discharge Current:100A
Battery Weight: 25Kg
Measurement: 82X76X32 cm
The lithium iron phosphate battery is a type of rechargeable battery based on the original lithium ion chemistry, created by the use of Iron (Fe) as a cathode material. LiFePO4 cells have a higher discharge current, do not explode under extreme conditions and weigh less but have lower voltage and energy density than normal Li-ion cells.
LiFePO4 widely used in electric sprayer, solar power general, energy storage devices, telecom base station, solar street light, UPS, ESS and so on.
