Model: VTC-LF271 Nominal capacity: 271Ah Internal Resistance: ≤0.33mΩ Life Cycles: ≥3000 Maximum Charge Voltage: 3.65V Cut-off Discharge Voltage: 2.3V Battery Weight: 5.5Kg Measurement: 173.9*71.5*207.3mm
Model: VTC-LF100A Nominal capacity: 100Ah Internal Resistance: ≤1mΩ Life Cycles: ≥3000 Maximum Charge Voltage: 3.65V Cut-off Discharge Voltage: 2.3V Battery Weight: 2.3Kgprismatic lifepo4 battery cells Specification: Model: VTC-LF100A Nominal capacity: 100Ah Internal Resistance: ≤1mΩ Life Cycles: ≥3000 Maximum Charge Voltage: 3.65V Cut-off Discharge Voltage: 2.3V Battery Weight: 2.3Kg Measurement: 48*173*132mm prismatic lifepo4 battery cells Application: 1. Light electric vehicles: such as electric bicycle, golf car, small-scale electric flat car, forklift, cleanness car, electric wheelchairs,Truck 2. Large-scale electric vehicles: such as bus, electric car, tourist car and commix car 3. Electric tool: electric drill, electric saw, lawn mower 4. Remote control cars, boat, aircraft, toys, 5. Solar and wind power generation energy storage devices 6. UPS emergency lights, warning lights and miners lamp 8. Small medical equipment and portable equipment prismatic lifepo4 battery cells Description: The lithium iron phosphate battery is a type of rechargeable battery based on the original lithium ion chemistry, created by the use of Iron (Fe) as a cathode material. LiFePO4 cells have a higher discharge current, do not explode under extreme conditions and weigh less but have lower voltage and energy density than normal Li-ion cells. prismatic lifepo4 battery cells Key Features： 1）Long cycle life: More than 2000 times (charging and discharging at 1C,remain capacity more than 80%) 2）Safety: No fire and explosion in overcharge test at voltage up to 30V in short-circuit test, Acupuncture test and heat shock up to 130℃ 3）High discharging rate to 30C 4）Excellent high temperature performance: operate in 85℃ could working well, have more wide operate temperature range than other battery. prismatic lifepo4 battery cells with related items: Measurement: 48*173*132mm
Model: VTC-16LF20 Nominal voltage: 48V Nominal capacity: 20Ah Internal Resistance: ≤12mΩ Life Cycles: ≥2000 Maximum Charge Voltage:58.4V Cut-off Discharge Voltage: 36.9V Continuous Discharge Current: 40A Battery Weight: 5.5Kg Measurement: 300*135*70mm
Model: VTC-16LF200 Nominal voltage: 48V Nominal capacity: 200Ah Internal Resistance: ≤100mΩ Life Cycles: ≥2000 Maximum Charge Voltage:58.4V Cut-off Discharge Voltage: 36.9V Continuous Discharge Current: 100A Battery Weight: 65Kg Measurement: 640*483*222mm
Model: VTC-16LF100 Nominal voltage: 48V Nominal capacity: 100Ah Internal Resistance: ≤80mΩ Life Cycles: ≥2000 Maximum Charge Voltage:58.4V Cut-off Discharge Voltage: 36.9V Continuous Discharge Current: 100A Battery Weight: 64Kg Measurement: 177*410*452mm
Model: VTC-4LF40 Nominal capacity: 40Ah Life Cycles: ≥2000 Maximum Charge Voltage: 14.6V Cut-off Discharge Voltage: 9.2V Battery Weight: 5Kg Measurement: 195*132*170mm
