LiFePO4 battery widely used in electric sprayer, solar power general, energy storage devices, telecom base station, solar street light, UPS, ESS and so on.
Model: VTC-4LF9
Nominal capacity:9Ah
Internal Resistance: ≤4mΩ
Life Cycles:≥2000
Maximum Charge Voltage:14.6V
Cut-off Discharge Voltage:9.2V
Continuous Discharge Current: 5A
Battery Weight: 1.15Kg
Measurement: 150mm*95mm*65mm
The lithium iron phosphate battery is a type of rechargeable battery based on the original lithium ion chemistry, created by the use of Iron (Fe) as a cathode material. LiFePO4 cells have a higher discharge current, do not explode under extreme conditions and weigh less but have lower voltage and energy density than normal Li-ion cells.
Model: VTC-16LF50
Nominal voltage:48V
Nominal capacity:50Ah
Internal Resistance: ≤100mΩ
Life Cycles:≥2000
Maximum Charge Voltage:58.4V
Cut-off Discharge Voltage: 36.9V
Nominal capacity:150Ah
Internal Resistance: ≤4mΩ
Life Cycles:≥2000
Maximum Charge Voltage:14.6V
Cut-off Discharge Voltage:9.2V
Continuous Discharge Current: 100A
Battery Weight:20.6Kg
Measurement:295*178*345mm
Model: VTC-4LF40 Nominal capacity: 40Ah Life Cycles: ≥2000 Nominal Voltage: 12.8V Maximum Charge Voltage: 14.6V Cut-off Discharge Voltage: 15.6V Battery Weight: 5Kg Measurement: 195 x 132 x 170 mm
