Model: VTC-LF30 Battery Type: Lifepo4 Nominal Capacity: 30Ah Nominal Voltage: 3.2V Battery Dimension: 20*110*140mm Battery Weight: 0.65Kg Internal Resistance: ≤2mΩ
Model: | VTC-LF30 |
Battery Type: | Lifepo4 |
Nominal Capacity: | 30Ah |
Nominal Voltage: | 3.2V |
Battery Dimension: | 20*110*140mm |
Battery Weight: | 0.65Kg |
Internal Resistance: | ≤2mΩ |
Cycle Life: | More than 2000 times, DOD at 80% |
Combination: | can be 4s 8s 12s 16s, etc |
Input Charging Voltage: | 3.65V/cell |
Input Charging Current: | Standard 20A, fast 40A |
Continuous Discharging Current: | 100Amps |
Max Current Discharge: | 300Amps |
Discharge cut-off Voltage: | 2.5V/cell |
Charging Temperature: | 0~45℃ |
Discharging Temperature: | -20~60℃ |
Storage Temperature: | -20~45℃ |
1) High energy density
2) Long cycle life
3) Wide application
4) High discharge rate
5) Safety: Excellent abuse tolerance and environmentally friendly
6) Life: Excellent calendar and cycle life.
The lithium iron phosphate battery is a type of rechargeable battery based on the original lithium ion chemistry, created by the use of Iron (Fe) as a cathode material. LiFePO4 cells have a higher discharge current, do not explode under extreme conditions and weigh less but have lower voltage and energy density than normal Li-ion cells.
Our Lifepo4 battery widely used for instrument,Solar supply system,solar panel, energy storage, electric tools, power tools, instruments, LED lighting devices, RC toys, inverter, household appliances and emergent device area, etc.
Model | Battery Material | Nominal Voltage(V) | Nominal Capacity | Internal Resistance | Life Cycles | Cut-off Discharge Voltage | Maximum Charge Voltage | Battery weight(Approx) | Measurement(Φ*H) |
VTC-LF14500C | LiFePo4 | 3.2V | 400mAh | ≦50 | ≥3000 | 2.3V | 3.65V | 18.5g | 14*50mm |
VTC-LF18500C | LiFePo4 | 3.2V | 1100mAh | ≦40 | ≥3000 | 2.3V | 3.65V | 32g | 18*50mm |
VTC-LF18650C | LiFePo4 | 3.2V | 1500mAh | ≦40 | ≥3000 | 2.3V | 3.65V | 45g | 18*65mm |
VTC-LF22650C | LiFePo4 | 3.2V | 2300mAh | ≦20 | ≥3000 | 2.3V | 3.65V | 60g | 22*65mm |
VTC-22650C | LiFePo4 | 3.2V | 3300mAh | ≦40 | ≥3000 | 2.3V | 3.65V | 80g | 26*65mm |
VTC-LF22650C | LiFePo4 | 3.2V | 3600mAh | ≦40 | ≥3000 | 2.3V | 3.65V | 83g | 26*65mm |
VTC-LF32650C | LiFePo4 | 3.2V | 6000mAh | ≦10 | ≥3000 | 2.3V | 3.65V | 195g | 32*65mm |
VTC-LF32700C | LiFePo4 | 3.2V | 6500mAh | ≦10 | ≥3000 | 2.3V | 3.65V | 198g | 32*70mm |
VTC-LF25 | LiFePo4 | 3.2V | 25Ah | ≦3 | ≥3000 | 2.3V | 3.65V | 690g | 22*100*140mm |
VTC-LF80A | LiFePo4 | 3.2V | 80Ah | ≦1 | ≥3000 | 2.3V | 3.65V | 2.3kg | 48*173*132mm |
VTC-LF80B | LiFePo4 | 3.2V | 80Ah | ≦1 | ≥3000 | 2.3V< | 3.65V | 1.8kg | 27*135*206mm |
VTC-LF100A | LiFePo4 | 3.2V | 100Ah | ≦1 | ≥3000 | 2.3V | 3.65V | 2.3kg | 48*173*132mm |
VTC-LF100B | LiFePo4 | 3.2V | 100Ah | ≦1 | ≥3000 | 2.3V | 3.65V | 2.08kg | 34*135*216mm |
VTC-LF120 | LiFePo4 | 3.2V | 120Ah | ≦1 | ≥3000 | 2.3V | 3.65V> | 2.84kg | 48*170*173mm |
VTC-LF202 | LiFePo4 | 3.2V | 202Ah | ≦1 | ≥3000 | 2.3V | 3.65V | 4.12kg | 54*174*208mm |
VTC-LF280 | LiFePo4 | 3.2V | 280Ah | ≦1 | ≥3000 | 2.3V | 3.65V | 5.5kg | 72*175*205mm |
Q1. Can I have a sample order for Battery?
A: Yes, we welcome sample order to test and check quality.
Q2. What about the lead time?
A:Sample needs 5-10 days, mass production time needs 25-30 days.
Q3. Do you have any MOQ limit for Battery?
A: Low MOQ, 1pc for sample checking is available
Q4. How do you ship the goods and how long does it take to arrive?
A: We usually ship by UPS, TNT... It usually takes 3-5 days to arrive. Airline and sea shipping also optional.
Q5. How to proceed an order for Battery?
A: Firstly let us know your requirements or application.Secondly We quote according to your requirements or our suggestions.Thirdly customer confirms the samples and places deposit for formal order.Fourthly We arrange the production.
Q6. Is it OK to print my logo on Battery?
A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
Q7: Do you offer guarantee for the products?
A: Yes, we offer 1-2 years warranty to our products.
Q8: How to deal with the faulty?
A: Firstly, Our products are produced in strict quality control system and the defective rate will be less than 0.2%.
Secondly, during the guarantee period, we will send new batteries with new order for small quantity. For defective batch products, we will repair them and resend them to you or we can discuss the solution including re-call according to real situation.
